Mander Pipe Organs

---

















	GREAT ORGAN		SWELL ORGAN
	Double Diapason	16	Open Diapason	8
	Open Diapason	8	Hohl Flute	8
	Stopped Diapason	8	Salicional	8
	Harmonic Flute	8	Celeste	8
	Principal	4	Principal	4
	Open Flute	4	Nason Flute	4
	Twelfth	2 2/3	Fifteenth	2
	Fifteenth	2	Piccolo	2
	Fourniture IV – V	1 1/3	Sesuialtera II	2 2/3
	Mounted Cornet V	8	Plein Jeu III - IV	1 1/3
	Trumpet	8	Basson	16
	Clarion	4	Trumpet	8
	Tremulant		Hautbois	8
	Swell to Great		Vox Humana	8
	Choir to Great		Tremulant
	Choir to Swell
			PEDAL ORGAN
	CHOIR ORGAN		Open Diapason	16
	Chimney Flute	8	Bourdon	16
	Quintadena	8	Quint	10 2/3
	Principal	4	Principal	8
	Block Flute	4	Bass Flute	8
	Nazard	2 2/3	Octave	4
	Fifteenth	2	Mixture IV	2 2/3
	Recorder	2	Trombone	16
	Tierce	1 3/5	Trumpet	8
	Mixture III – IV	1	Great to Pedal
	Cromorne	8	Swell to Pedal
	Tremulant		Choir to Pedal
	Swell to Choir
	Peake Trumpet *	8
	* Playable from Great and Choir keys, an existing stop now places behind a screen in the Chancel
